The objective of this research was to study influence of five different kinds of the mordant copper sulfate (CuSO4) ferrous sulphate (FeSO4) alum and chitosan on dyeing properties of cotton yarn with natural dye extracted from teak leaves. Cotton yarn dyeing with the extracted dye from teak leaves was carried out at 60?C for 30 minutes with a material to liquor ratio of 1:5. Three mordanting methods such as pre mordanting simultaneous mordanting and post mordanting were used. After that dyed clothes were subjected to measurement using CIELAB system and fastness tests. The effect of kinds of mordents on the hue of dyeing of cotton yarn shown that CuSO4 FeSO4 gave greenish yellow and yellowish brown respectively. While as alum and chitosan gave violet red. Moreover using CuSO4 (pre mordanting or simultaneous mordanting) and FeSO4 (simultaneous mordanting) improved fastness properties to light better than without a mordant.

The purposes of this research were1) to study the process of dried banana leaves’ dyeing with natural dye and scientific dye and 2) to study the results of dried banana leaves’ dyeing with natural dye and scientific dye. Dried banana leaves were bleached by using three formulas as follows: 1. Mix Haiter with water in the ratio 1:1 2. Mix Haiter with water in the ratio 2:1 and 3. Mix Haiter with water in the ratio 3:1. Soak 300 grams of the dried banana leaves for 5 days and record the results. The result of this experiment indicated that the third formula wassuitable to whiten and toughen dried banana leaves. After choosing the suitable formula for bleaching

The purpose of this research was to study the white resist printing with colour resistant material from flour of wild taro (Colocasia Esculenta (L.) Schott) and using reactive pigment and natural dyes as dyestuffs. Five formulas of printing pastes were applied to light cotton thick cotton and silk fabrics by the use three techniques nauely Silk screen (White resist and colour resist methods)stencil and batik. The optimal ratio of colour resistant materials from flour of wild taro were compose of 20 grams flour of wild taro 32-36 ml. water 30-34 ml. sodium chloride 10-13 ml. calcium hydroxide and 1-4% vegetable oil. The viscosities of printing paste from five recipes were shown in the rage between 559.9-671.9 Centipoise. All five recipes can resist dyestuffs and also easy to remove the flour of wild taro. The pattern at resist printing area of fabrics shows sharpness and whiteness. The colour fastness to washing water and perspiration on cotton and silk fabric results were ranging between poor to fair level when using reactive and natural dyes as dyestuff. However the fastness property of pigment dye shows medium to good level. The colour fastness to rubbing is shown to be in range of 4 to 4-5 for all recipes. The ratings of colour fastness to light in terms of colour change are fair to good (4 to >6).

This research had an aim to develop an autoclave for using in natural dyes extraction and dyeing process. The autoclave used the stainless steel as the major material what it was a noble durable material and good resistance for the chemical used in the processes. The achievement results showed by the comparison data between the conventional process and the development using autoclave in term of extraction efficiency deep of shade (K/S) time equivalent process time and amount of gas consumption saver. The knowledge from the research would transfer to the target group at Bann Yang Nam Klad Tai Phetchaburi province. The results were following as 1. For the extraction process: the extraction process using 100oC for 45 min. They obtained product was the same dye quality but the autoclave process was smaller water evaporation as 26.71% whereas the conventional process was 41.99%. 2. For the dyeing process: All condition from the autoclave using make a deeper dye shade (K/S) than conventional process. The dyeing time equivalent as 15 minutes to make the depth shape via autoclave process as alike the conventional process for 45 min. 3. Saving time and gas consumption: the autoclave process could save 66.67% time process and 88.99% amount of gas consumption. 4. The Complacency for knowledge assignment: the satisfaction level in the content time and period was good. Furthermore the utilization the instructors and the value obtained were excellent. This research accomplished the study objectives. The results were not only corresponding to energy conservation but them also reducing the chemical toxic and pollutant vapor inhalant to the worker.

This study was investigated the pretreatment of dye effluent from dyeing process by activated carbon. The study parameters were color strength operating time and types of dyestuff such as direct dye reactive dye acid dye basic dye and disperse dye. The results found the activated carbon was achieved to adsorb the colorant. The pretreatment process used 100 – 200 gram activated carbon to one liter of dye effluent. The contact time was 2 hours at room temperature. The dyeing conditions had an influent for pretreatment process. The acidic condition was favored than neutral and basic condition. In addition the dye removal efficiency was basic dye > acid dye > disperse dye > direct dye > reactive dye.
