The objectives of this research are to study the production to find the proper ratio to test the physical mechanical properties and thermal conductivity to suggest the implementation and to transfer the technology of l ight-weight precast concrete wall panel product with aerated foam injection technique as core wall. The light-weight precast concrete wall panel product was produced by casting the mortar panels with M3 ratio (proper ratio) set up the steels and injecting the aerated foams. From the testing results followed the TIS.2226-2548 and TIS.878-2537 the general characteristic of light-weight precast concrete wall panel product was perfect. The properties of light-weight precast concrete wall panel product include 17.81 MPa of compressive strength no bending when installed in common behavior 11.38% of water absorption passed in type1 of hardness and impact test 1110.58 kg/m3 of density 9.18 MPa of bending strength and 0.186 watt/m.K of thermal insulation. This light-weight precast concrete wall panel product can use as the thermal insulation wall in building. the developing product can apply to register the petty patent.

This research aims to study the using cassava pit wastes mixed with cement to particle board walls. The Portland cement type1: fine sand: tap water ratio is equal to 1: 0.5: 0.416 by weight. The ratios of cassava pit wastes to cement are used following: 0.05 0.06 0.07 0.08 0.09 and 0.10 by weight. The cassava pit wastes are crushed by plastic plastics granulators (pass sieve no.4). The casting of particle board walls use the compression machine in room temperature (30 – 35 degree of Celsius) and control 0.75 g/cm3 of density. The TIS 878-2537 standard (cement bonded particle board: high density) is followed to test the properties of particle board wall. Resulting the cassava pit wastes mixed with cement can cast to particle board walls and have good properties especially the thermal insulation property.

The using of ground coffee wastes from industries to develop the cement board is an objective of this research that can solve the air pollution problems from smell and spreading of ground coffee wastes. The ratio of Portland cement type1: fine sand: tap water is equal to 1: 0.5: 0.416 by weight and the ratios of Portland cement type1: ground coffee wastes include 1: 0.05 1: 0.06 1: 0.07 1: 0.08 1:0.09 and 1: 0.10 by weight (6 ratios). The production of cement board uses the pressure casting in temperature 30 – 35 degree of Celsius and controls 0.75 g/cm3 of density. The testing of cement-bonded fiberboard properties follow the TIS 878-2537 standard (cement bonded particle board: high density). From the results 1: 0.05 is the most suitable quantity of cement: ground coffee wastes which mixed in cement board. This cement boards can reduce the ground coffee wastes by using as aggregate to produce the construction materials.

This research aims to study the properties of natural rubber STR 20 at 100 phr with various contents of coir (e.g. 0 5 10 20 40 and 80 phr) and then mixed with chemical substance at constant ratio. After that the samples are ground by two-roll mill and formed by compression molding at 150 degree Celsius. This leads into the coir reinforcement natural rubber plate of dimension 30x30x0.5 cm. The properties of the natural rubber plates are tested under ASTM standard. From the results it is found that increasing in coir then the properties of resilience and density are improved at every mix ratio. However the tensile strength tear strength and wearing are increased at some certain value of coir. The samples give no water absorption at every mix ratio. The results from this research indicate that it can develop into the rubber floor tiles and rubber wall tiles for furnishing the buildings in natural style.

This research aims to develop the cement board from coconut shell ash. The Portland cement type1: fine sand: tap water ratio is equal to 1: 0.4: 0.33 by weight. The 5 ratios of Portland cement type1: coconut shell ash include 1: 0.12 1: 0.13 1: 0.14 1: 0.15 and 1: 0.16 by weight. The cement board production uses the pressure casting in normal temperature (30 – 35 degree of Celsius) and controls the 0.75 g/cm3 of density then test the properties of cement-bonded fiberboard follow TIS 878-2537 standard (cement bonded particle board: high density). From the results 1: 0.12 is the most suitable ratio of cement board from coconut shell ash. This developed cement boards can reduce the quantity of coconut shell ash waste and have the good thermal insulation.
