This study is meant to help develops better facilities for Tungsten Carbide powder production process. The 10 kg-capacity machine used was able to produce 85 -95.49 percent purity Tungsten carbide powder. When measured most of the particle sizes and distribution between 0.03-350.00 !lm. which are considered large sized. More than that those tungsten carbide particles are contaminated by other kinds of metal especially Cobalt binder. We have tried to improve the Tungsten Carbide manufacturing processes by combining more steps including ball milling drying and screening. After 24-hours ball milling process the result showed that we were able to produce smaller Tungsten Carbide paliicles sizing from 0.025 to 30.00 ~lm. The obtained particles are also rounder and with 99.50 percent purity. They are also easier to grade. The Tungsten Carbide manufacturing technology yet needs a further development to eventually produce the desired hard material.

This research is to study the recycle process of hard materials high hardness type and cemented carbide produced by press forming and sintering process included cemented carbide mixed with tungsten carbide cobalt silicon titanium and others. The research aims to recovery tungsten to use it again. It starts in cleaning and ball milling materials for resizing from length 12-25 mm. width 10-15 mm and thickness 2.5-8.0 mm. then disintegrated with the electric-chemical process filtering metal powder cleaning and drying. The result of dissolved materials with electricchemical process in 85% condensed HCl 6-24 volts and 3-10 amperes. The solution heats up 180 degree Celsius is found that material will be 550 11m of W03 the same as usage of Phosphoric Solution. The result of the study in dissolved materials by using the conductor of electricity is found that usage of cobalt is the best to disintegrate tungsten carbide better than tungsten carbide and stainless steel 10-15%. The result of this research is found that the best practice of tungsten carbide recovery is dissolved materials with electric-chemical process in not over 7N condensed HCl 6.00 volts and 3.00 amperes. The metal powder will be almost 100% pure tungsten carbide and particle sized distribution is 34-360 11m. After ball milling for 24 hours particle sized distribution is less than 60 11m compared with the imported metal powder. It is concluded that the recycle of cemented carbide into tungsten carbide powder qualified for sintering work and produced to the durable hard materials. It ensures that this research is useful for the related industry and the approach for production of tungsten carbide which was instead of the imported metal powder.

This research aimed to study the use of coarse aggregate obtained from removing old recycled asphalt pavement (RAP) in the production of the porous concrete paving block. Crushing and size separation of the coarse aggregate by using standard sieve size by selected the gradation size of the coarse aggregate that passed to sieve size 1/2” and retained on sieve size 3/8” and other that passed to sieve size 3/8” and retained on sieve size No.4 by mixing ratio 50 : 50 of the mass as replaced natural coarse aggregate. Portland cement quantity about 18% and 20% by weight of the aggregate. The water to cement ratio was 0.30 and 0.35 respectively. Compressive strength flexural strength and water permeability were investigated. The results showed that the cement content and water to cement ratio was influenced the strength properties and water permeability rate of the porous concrete paving block. The porous concrete paving block mixed with higher cement content (20%) had the compressive strength at the age of 28 days increased by 16-24% when compared with lower cement content (18%). On the other hand the water permeability rate decreased by 5.1-8.1%.

During the epidemic of the coronavirus covid-19 single-use plastic containing products were in high demand across the community and may not be cost effective to recycle. However repurposing such materials can reduce their environmental impact for instance plastic foam waste can be made into pots for planting different types of plants and trees. By mixing the foam with a suitable cement in a ratio of 1:1 a large range of pot diameters from 4.5-10 inches can be produced suitable for both indoor and outdoor planting requirements. These pot products suitable for growing plants of all sizes are durable unbreakable water tight. Therefore it is a product that repurposes the leftovers from the community and may even add value. This strategy helps reduce the problem of waste and in particular encourages replenishment of green space to nature and the environment which also helps to combat global warming.

This research is a survey study. And analyze the waste composition And guidelines for the use of seafood waste in the Thai seafood market Samut Sakhon Province According to the survey 96.27 percent of the waste comes from restaurants. This is because Most fresh seafood restaurants Will feed the seafood whole Therefore there is no garbage such as shrimp if it is a restaurant the customers will have left shrimps on the head. But the fresh restaurants give away the shrimp and crab so the garbage from the fresh restaurant only has fishbone which is very small. Because most customers accept the whole fish There were also some places where the vendors cut the fish and left their bones. But when analyzed by type of waste it found that shell waste was the highest. Which is up to 55.29 percent. Followed by shrimp shells fish bone and fish heads and crab shells the study found that seafood debris had material properties with low moisture content. It also contains calcium as the main component. For example shellfish contain calcium as the main component which is found in approximately 98.50 percent. Not only striped shells Fishbone shrimp and crab shells are also low humidity and high in calcium. The bizarre one was holding a sea bass head and a grouper head with a high amount of organic matter. And with low ash content food waste that should be analyzed for the possibility of recycling are striped shells cockle shells shrimp shells fishbone shells fishbone dumplings tuna and crab shells.
